Compatibility
Compatible hub models
- Hub Hybrid (2G)
- Hub Hybrid (4G)
Compatible range extenders
Range extenders with Fibra devices support will soon be added to the Ajax devices product line.
Communication
Fibra communication technology. Proprietary wired communication technology. Fibra combines the reliability of wires with the freedom of radio connection.
It features:
- Two-way communication.
- Advanced anti-sabotage.
- Instant notifications.
- Remote configuration via the app.
Bus connection
- 4-core cable
- Bus line length up to 2,000 meters when using the U/UTP cat.5 twisted pair.
- Wired devices connection
- Number of zones 18 wired zones
- Multiple devices can be connected to one zone. The number of connected devices depends on their power consumption.
- Type of connection NC, NO, EOL, 2EOL, 3EOL with EOL resistance from 1 kΩ to 30 kΩ with 100 Ω increment.
- Cable length up to 400m when using a copper signal cable with a 0.22 mm² cross-sectional area of the conductor.
- Operation mode pulse, bistable
- Event type:
- 7 types of alarms for each wired zone
- tamper alarm
- intrusion
- fire alarm
- medical help
- panic button
- gas concentration alarm
- malfunction
- Adjusted by PRO or user with admin rights in the Ajax app
- Enclosure Dimensions: 192 × 238 × 100 mm
- Weight: 798g
- Operating temperature range: from −10°C to +40°C\
- Operating humidity: up to 75%
- Protection class: IP40
